TX140 S1 Upgrade and Maintenance Manual 205
8 System fan and air duct
This chapter provides information on how to replace the system fan module.
Basic information
Figure 95: Fan module
The PRIMERGY TX140 S1 server features only one system fan module. The
fan module consists of the system fan contained in an air duct directing airflow
directly onto the CPU heat sink and memory slots.
I Additional fans in PSU modules are integral parts of the power supply
units and cannot be replaced separately.
[1] C26361-K835-B239 Air duct with fan holder
[2] A3C40089133 System fan 120 x 38 mm
