574 Upgrade and Maintenance Manual TX140 S1
Appendix
17.2 Configuration tables
17.2.1 Hard disk drives / solid state drives mounting order
Please refer to chapter "Hard disk drives / solid state drives" on page 159.
17.2.2 Memory board configuration table
Please refer to chapter "Main memory" on page 293.
17.2.3 Expansion card configuration table
Please refer to chapter "Expansion cards and backup units" on page 223.
7 Battery backup unit "Replacing a BBU" on page 266
8
SAS / SATA HDD / SSD
backplane
– "Replacing the 2.5-inch HDD
SAS / SATA backplane" on page 185
– "Replacing the 3.5-inch HDD
SAS / SATA backplane" on page 194
9 HDD / SSD drive bay
"Hard disk drives / solid state drives" on
page 159
10 Front panel module bay "Replacing expansion cards" on page 238
11 Accessible drive bay "Replacing the fan module" on page 207
12 System board D3049
"Replacing the system board" on
page 451
13 Memory modules
"Replacing memory modules" on
page 303
14
Standard power supply
unit
"Replacing the standard power supply unit"
on page 124
Pos. Component Reference
