TX140 S1 Upgrade and Maintenance Manual 291
Expansion cards and backup units
Ê Pull the SFP+ transceiver module out of its socket connector.
Ê Reattach the protective optical port plug to the transceiver optical bores.
I Place the removed SFP+ transceiver module in an antistatic bag or
other protective environment.
9.4.2.3 Replacing SFP+ transceiver modules
For Fiber Channel over Ethernet (FCoE) configurations, the ethernet server
adapter is equipped with one or two SFP+ (small form-factor pluggable)
transceiver modules.
Required tools
● Preliminary and concluding steps: tool-less
● Removing SFP+ transceiver modules: tool-less
Removing SFP+ transceiver modules
Ê Remove the defective SFP+ transceiver module(s) as described in section
"Removing an SFP+ transceiver module" on page 289.
Installing SFP+ transceiver modules
Ê Unpack the new SFP+ transceiver module.
Ê Verify that the new SFP+ transceiver module is the same type of transceiver
you are replacing.
Ê Install the new SFP+ transceiver module(s) as described in section
"Installing SFP+ transceiver modules" on page 284.
Ê Inform the customer about changed WWN and MAC addresses. For further
information, refer to section "Looking up changed MAC / WWN addresses"
on page 117.
I By replacing SFP+ transceiver modules, WWN (World Wide Name)
and MAC (Media Access Control) addresses will change.
Upgrade and Repair Units (URU)
Average task duration: 5 minutes
