Cabling
16.1 Cabling overview
No. Name
Cable
number
Routing
2.5"
HDD
model
3.5"
HDD
model
1
Front panel
connector cable
T26139-
Y4015-V1
from front panel
module to system
board
oo
2 Power cable
T26139-
Y4012-V501
from all drives to
system board
oo
3 ODD SATA cable
T26139-
Y3928-V205
from optical disk
drive to system
board
oo
4
SAS / SATA
cable
T26139-
Y3963-V101
from 2.5-inch
HDD backplane
to system board
or SAS controller
oo
5 Mini SAS cable
T26139-
Y3969-V301
from LTO Backup
drive to SAS
controller
oo
6 USB cable
T26139-
Y3973-V2
from USB backup
drive to system
board
oo
7
If BBU installed:
BBU cable
(I
2
C bus)
T26139-
Y3987-V2
from BBU to
RAID controller
oo
If FBU installed:
FBU adapter
cable
T26139-
Y4032-V2
from FBU to
RAID controller
oo
8 Front LAN cable
T26139-
Y4025-V1
from server front
to front LAN
board D2935
oo
9
Intrusion switch
cable
T26139-
Y3736-V302
from server front
to system board
oo
Table 11: List of used cables
