TX140 S1 Upgrade and Maintenance Manual 69
Basic hardware procedures
4.5.1.2 Removing the rack front cover
I The rack front cover consists of the rack mounting frame and the front
bezel. For further information, refer to section "Assembling the rack front
cover" on page 482.
Figure 14: Removing the ID card (rack server)
Ê Remove the ID card from the server front.
Figure 15: Removing the front cover (rack server) (A)
Ê Remove two screws from the side brackets on either side of the rack
mounting frame.
