510 Upgrade and Maintenance Manual TX140 S1
Cabling
Ê When working on a rack-mounted server, secure it in the rack as described
in section "Sliding the server into the rack" on page 89.
If the server has been completely removed from the rack for maintenance
purposes, reinstall and secure it in the rack as described in section
"Mounting the server in the rack" on page 87.
Ê Reconnect the AC power cord to the power supply unit and secure it with a
cable tie as described in section "Connecting the server to the mains" on
page 90.
Ê If applicable, close the rack door as described in section "Closing the rack
door" on page 92.
16.3 Replacing the power cable
Figure 342: Power cable T26139-Y4012-V501
Field Replaceable Units (FRU)
Average task duration: 10 minutes
