TX140 S1 Upgrade and Maintenance Manual 337
Accessible drives
12.2.5 Installing a slimline optical disk drive (ODD)
12.2.5.1 Mounting the slimline drive in the slide-in unit
Figure 190: Slide-in unit for slimline ODD
Figure 191: Mounting the slimline ODD in the slide-in unit (A)
Ê Insert the slimline ODD on the top.
Ê Fasten it with one M2 x 2.5 mm screw (C26192-Y10-C62) to the slide-in unit
on the right side.
