Husqvarna TE 250 Workshop Manual

F.2 Part. N. 8000 B0148 (02-2008)
ENGINE DISASSEMBLY
Cylinder head cover disassembly .............................. F.4
Camshaft disassembly .............................................. F.4
Water pump body disassembly ................................. F.6
Cylinder head disassembly ....................................... F.7
Valve disassembly .................................................... F.8
Cylinder disassembly ................................................ F.10
Piston disassembly ................................................... F.10
Flywheel disassembly ............................................... F.11
Kick start pedal disassembly (TC, TE, TXC) .............. F.12
Transmission cover disassembly .............................. F.13
Clutch disassembly (TC, TE, TXC; SMR 450-510) .... F.13
Clutch disassembly (SMR 450 R) ............................. F.15
Kick start components disassembly (TC, TE, TXC) ... F.17
Electric starting system disassembly
(TE, TXC; SMR 450-510) .......................................... F.18
Oil pump disassembly ............................................... F.19
Gear control pedal and gear shifter
disassembly .............................................................. F.20
Primary transmission driving gear
disassembly .............................................................. F.22
Crankcase disassembly ............................................ F.23
Gearbox disassembly ............................................... F.24
Crankshaft and counter balancing shaft
disassembly (SMR 450-510) ..................................... F.26

Husqvarna TE 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Cooling System	Liquid
Starter	Electric
Front Suspension	WP XPLOR 48
Front Brake	Disc brake
Rear Brake	Disc brake
Bore x Stroke	66.4 mm x 72 mm
Engine Type	2-Stroke
