Husqvarna TE 250 Workshop Manual

G.8 Part. N. 8000 B0148 (02-2008)
ENGINE OVERHAULING
Tap gently on the valve stem with a plastic hammer to make the cotters seat.
Hit straight on the top of the valve stem so that the valve stem
doesn’t get out of true.
Inspection of rocker arm
Check the clearance between the rockerarm and the rocker arm shaft. Measure
the inner diameter of the rocker arm and the outer diameter of the rocker arm
shaft and accurately determine the clearance. Maximum clearance 0.04 in. If
greater, replace the two rocker arms. When reassembling tighten rocker-arm
axles to 25 Nm-2,55 Kgm18.4 ft/lb. (+LOCTITE 243).
Starter decompressor
Check that starter decompressor rotate freely. If there is an oil leak, change the
O-ring.

Husqvarna TE 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Cooling System	Liquid
Starter	Electric
Front Suspension	WP XPLOR 48
Front Brake	Disc brake
Rear Brake	Disc brake
Bore x Stroke	66.4 mm x 72 mm
Engine Type	2-Stroke
