Husqvarna TE 250 Workshop Manual

P.5Part. N. 8000 B0148 (02-2008)
HYDRAULIC CONTROL CLUTCH
Bleeding of the hydraulic system
Proceed as follows:
- remove screws (1), cap (2) and rubber pump diaphragm (4);
- remove the rubber cap (3) and the bleeding nipple (5);
- mount a syringe in the bleeding nipple hole, then refill with fresh fluid (see
LUBRICATION TABLE on page A.9).
: NEVER use brake fluid.
- refill until fluid is discharged from the lower hole (B) on the pump body WITHOUT
BUBBLES. The fluid level MUST NEVER BE below 4 mm from the top (A) of the
clutch pump body (see picture). Reassemble the removed parts.

Husqvarna TE 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Cooling System	Liquid
Starter	Electric
Front Suspension	WP XPLOR 48
Front Brake	Disc brake
Rear Brake	Disc brake
Bore x Stroke	66.4 mm x 72 mm
Engine Type	2-Stroke
