Husqvarna TE 250 Workshop Manual

H.32 Part. N. 8000 B0148 (02-2008)
ENGINE REASSEMBLY
Reassembly of flywheel
Clean the flywheel rotor removing any debris gathered in centrifugated oil and
attracted to the magnets. Reassembly the Woodruff key and the rotor on the
crankshaft. Holding the rotor (on the R.H. side place an aluminium shim between
the teeth of the primary drive gears, in order to prevent its rotation), mount the nut
and tighten it to 75 Nm-7,65 Kgm- 55.3 ft/lb. Mount the two centering bushes.

Husqvarna TE 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Cooling System	Liquid
Starter	Electric
Front Suspension	WP XPLOR 48
Front Brake	Disc brake
Rear Brake	Disc brake
Bore x Stroke	66.4 mm x 72 mm
Engine Type	2-Stroke
