Husqvarna TE 250 Workshop Manual

SETTINGS AND ADJUSTMENTS
Part. N. 8000 B0148 (02-2008) D.27
B: axis of the panel screw
C: axis of rear wheel pin
C
A
B
Adjusting the shock absorber
The rear shock absorber must be adjusted according to the rider weight and track conditions.
Proceed as follows:
1. With motorcycle on the stand, measure distance (A).
2. Take the normal riding position on the motorcycle with all your riding apparel.
3. With somebody’s help, take the new distance (A).
4. The difference between these two measurements constitutes the “SAG” of the motorcycle’s rear end.
Suggested SAG: 4 in. with cold shock absorber. 3.7 in. with warmed up shock absorber.
5. To get the right SAG according to your weight, adjust the shock absorber spring preload (D.28).

Husqvarna TE 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Cooling System	Liquid
Starter	Electric
Front Suspension	WP XPLOR 48
Front Brake	Disc brake
Rear Brake	Disc brake
Bore x Stroke	66.4 mm x 72 mm
Engine Type	2-Stroke
