Husqvarna TE 250 Workshop Manual

F.7Part. N. 8000 B0148 (02-2008)
ENGINE DISASSEMBLY
Cylinder head disassembly
TE-SMR: remove the coolant fluid temperature sensor with its O-ring.
Remove the two screws on the L.H.S (8 mm wrench) then the front nut under the
cylinder head (13 mm wrench).
Remove the four inner screws on the cylinder head (10 mm wrench) whilst
following a cross-over pattern.
Remove the cylinder head and relative gasket.

Husqvarna TE 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Cooling System	Liquid
Starter	Electric
Front Suspension	WP XPLOR 48
Front Brake	Disc brake
Rear Brake	Disc brake
Bore x Stroke	66.4 mm x 72 mm
Engine Type	2-Stroke
