Husqvarna TE 250 Workshop Manual

M.4 Part. N. 8000 B0148 (02-2008)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
KEY TO ELECTRIC DIAGRAM
(TC-TXC 250)
1. Electronic power unit
2. Alternator
3. Voltage regulator
4. Condenser
5. Battery
6. Electric start remote control switch
7. Starting motor
8. Spark plug
9. Gear shift position sensor
10. Electronic coil
11. Carburetor throttle position sensor
12. Engine stop
13. Engine start
14. Clutch microswitch
Cable colour coding
B Blue
Br
Brown
Bk Black
G Green
Gr Grey
Gr/R Grey/Red
O Orange
PPink
R Red
Sb Sky blue
V Violet
W White
Y Yellow
R-W
G
BK-R
R-W
W-Br
G
R
BK-R
R
CANDELA
BOBINA
GENERATORE
W-O
SENSORE MARCE
SENSORE APERTURA
FARFALLA
REGOLATORE
CONDENSATORE
-
+
15A
ARRESTO
MOTORE
BATTERIA
TELERUTTORE
MOTORINO
AVVIAMENTO
Y-G
B
Bk
Y
B
R
Bk
B-W
W
B
Bk
Y
CENTRALINA
Bk
-
+
R
G-O
R
R
O
R
Bk-W
B
Y
Y
R
R
Bk
AVVIO
MOTORE
B-W
Bk
R
INTERR.
FRIZIONE
SCHEMA PER INSERIMENTO AVVIAMENTO ELETTRICO
1
2
3
4
5
6
7
8
10
9
11
12
13
14
*
*: ELECTRIC STARTER KIT

Husqvarna TE 250 Specifications

General

Displacement	249 cc
Transmission	6-speed
Cooling System	Liquid
Starter	Electric
Front Suspension	WP XPLOR 48
Front Brake	Disc brake
Rear Brake	Disc brake
Bore x Stroke	66.4 mm x 72 mm
Engine Type	2-Stroke
