M.43Part. N. 8000 B0148 (02-2008)
ELECTRIC SYSTEM, DIGITAL INSTRUMENT
CABLE RUNWAY AND ASSEMBLING INSTRUCTIONS
FOR THE ‘TE/SMR’ ELECTRIC PARTS
• A.T.coil positioning
Make sure the coil cable is facing the rear part of the motorbike.
• Relay positioning (3 parts)
R.S. relay.
• Turn indicators flash device positioning
Turn indicators flash device
L.S. relay.
