H.31Part. N. 8000 B0148 (02-2008)
ENGINE REASSEMBLY
Reassembly of timing system drive gear and chain
The key for the cam chain sprocket must be installed with the cut end out towards
the drive gear.
Lubricate the cam-chain sprocket and install it on the crankshaft using a drift.
Reassemble the cam drive chain.
Reassemble the flywheel key, the spring and the flywheel.
