J.9
Part. N. 8000 B0148 (02-2008)
REAR SUSPENSION
Checking the adjustment
In case of compression adjustment for operating defect, it is necessary to
unscrew the knob stopping dowel (before unscrewing, heat with warm air).
Proceed as follows:
unscrew the ring nut with a suitable wrench, extract the parts paying attention to
the dismantling sequence in order to correctly effect then the reassembly.
