J.10
Part. N. 8000 B0148 (02-2008)
REAR SUSPENSION
After having completed the check, insert again the piston, the disk, the spring and
the ring with slots. Remove the cone holding shaft from the plug, screw the ring
and insert it in the slot applying a light pressure. Lock the assembly with the plug
at a torque of 30 Nm (3 kgm; 29.2 ft/lbs).
It is strictly forbidden to replace the compression blades with other
types of blades, as blades different from the original ones can cause
the explosion of the shock absorber during use.
Reservoir replacement
In case of reservoir replacement, it is necessary to heat with warm air near the
screwed side and unscrew it with a suitable tool.
Replace the O-Ring of the reservoir. Grease the OR surface, but see that the base
thread gets not smeared with grease.
