CHAPTER 13

Cable Specifications and Pinouts

IN THIS CHAPTER

Console Port Cable and Wire Specifications for the SRX3600 Services Gateway | 91

Signal-Distance Limitations for the SRX3600 Services Gateway | 92

Radio Frequency Interference for the SRX3600 Services Gateway | 92

Electromagnetic Compatibility for the SRX3600 Services Gateway | 92

Signal Loss in Multimode and Single-Mode Fiber-Optic Cable for the SRX3600 Services Gateway | 93

Attenuation and Dispersion in Fiber-Optic Cable for the SRX3600 Services Gateway | 94

Calculating the Power Budget for Fiber-Optic Cable for the SRX3600 Services Gateway | 95

Calculating the Power Margin for Fiber-Optic Cable for the SRX3600 Services Gateway | 95

Console Port Cable and Wire Specifications for the SRX3600 Services

Gateway

Table 28 on page 91 lists the specifications for the cable that connects a CONSOLE port on the Routing

Engine to a management console.

Table 28: Cable and Wire Specifications for Routing Engine Management and Alarm Interfaces

Receptacle

Maximum

LengthCable/Wire SuppliedCable SpecificationPort

RJ-45/DB-9

male

6 ft (1.83 m)One 6-ft (1.83-m) length

with RJ-45/DB-9

connectors

RS-232 (EIA-232)

serial cable

Routing Engine

console or auxiliary

interface
