RELATED DOCUMENTATION
SRX1400, SRX3400, and SRX3600 Services Gateway Module Overview | 27
Modules Supported on SRX1400, SRX3400, and SRX3600 Services Gateways | 28
Eligible Slots for SRX1400, SRX3400, and SRX3600 Services Gateway Modules | 30
Installing Common Form Factor Modules In SRX1400, SRX3400, and SRX3600 Services Gateways
I/O Card SRX3K-2XGE-XFP
The SRX3K-2XGE-XFP (Figure 22 on page 40) IOC adds two ports for 10-Gigabit Ethernet traffic from
fiber interface media. It is inserted horizontally into the midplane of the services gateway to communicate
with the Switch Fabric Board (SFB) and to receive power. To use fiber interface media, install 10-Gigabit
small form-factor pluggable (XFP) transceivers on the desired ports. LEDs on the faceplate of the IOC
indicate port status and connectivity (see Table 15 on page 27). Ports are numbered from left to right, 0-1.
Figure 22: 2-Port XFP 10-Gigabit Ethernet IOC
For detailed information about supported transceivers, see the SRX Series Services Gateway Transceiver
Guide at www.juniper.net/documentation/.
•
2-port Ethernet XFP IOC for SRX3400, SRX3600, and SRX1400
•
Power requirement: 52 W maximum
•
Weight: 2.4 lb (1.1 kg)
•
Maximum configurable MTU: 9192 bytes
Description
•
Junos OS Release 9.3 and laterSoftware release
40
