RELATED DOCUMENTATION
Replacing the Air Filter on the SRX3600 Services Gateway | 226
Required Tools and Parts for Maintaining the SRX3600 Services Gateway Hardware Components | 167
Routine Maintenance Procedures for the SRX3600 Services Gateway | 168
Maintaining the Fan Tray on the SRX3600 Services Gateway | 169
Maintaining the Routing Engine on the SRX3600 Services Gateway | 170
Maintaining the Power Supplies on the SRX3600 Services Gateway | 172
Maintaining the Fan Tray on the SRX3600 Services Gateway
The fan tray contains multiple fans that work in unison to cool the services gateway components. If one
fan fails, the Routing Engine adjusts the speed of the remaining fans to maintain proper cooling. A red
alarm is triggered when a fan fails, and a yellow alarm and red alarm is triggered when a fan tray is removed.
To display the status of the cooling system, issue the show chassis environment command. The output is
similar to the following:
user@host> show chassis environment
Class Item Status Measurement
Temp PEM 0 OK
PEM 1 OK
Routing Engine 0 OK
Routing Engine 1 Absent
CB 0 Intake OK 36 degrees C / 96 degrees F
CB 0 Exhaust A OK 43 degrees C / 109 degrees F
CB 0 Mezz OK 45 degrees C / 113 degrees F
CB 1 Intake Absent
CB 1 Exhaust A Absent
CB 1 Mezz Absent
FPC 0 Intake OK 35 degrees C / 95 degrees F
FPC 0 Exhaust A OK 35 degrees C / 95 degrees F
FPC 0 Exhaust B OK 36 degrees C / 96 degrees F
FPC 0 SF OK 50 degrees C / 122 degrees F
FPC 1 Intake OK 34 degrees C / 93 degrees F
FPC 1 Exhaust A OK 41 degrees C / 105 degrees F
FPC 1 XLR OK 53 degrees C / 127 degrees F
169
