SRX3600 Services Gateway NP-IOCs
Network Processing I/O Cards (NP-IOCs) are IOCs designed specifically for low-latency applications. Each
NP-IOC has its own network processing unit (NPU), so that traffic traversing the NP-IOC does not have
to traverse the services gateway bus to a remote network processing card (NPC). It is inserted horizontally
into the midplane of the services gateway to communicate with the Switch Fabric Board (SFB) and to
receive power. Figure 6 on page 17 shows a typical NP-IOC.
Figure 6: Typical NP-IOC
NOTE: You can install NP-IOCs instead of NPCs and IOCs in the services gateway. However, if no
NPCs are present, the Ethernet ports on the SFB will not be functional.
For detailed information about the NP-IOCs supported by the services gateway, see the SRX1400, SRX3400,
and SRX3600 Services Gateway Module Guide at www.juniper.net/documentation/.
RELATED DOCUMENTATION
SRX3600 Services Gateway Chassis | 21
Installing CFM Cards in the SRX3600 Services Gateway | 125
Available Components for the SRX3600 Services Gateway | 5
SRX3600 Services Gateway Switch Fabric Board | 7
SRX3600 Services Gateway NPCs | 14
SRX3600 Services Gateway SPCs | 15
