SRX3600 Services Gateway AC Power System Electrical Specifications
Table 18 on page 76 lists the AC power system electrical specifications.
Table 18: AC Power System Electrical Specifications
SpecificationItem
Operating range: 100-127 V / 200-240 VAC input voltage
50 / 60 HzAC input line frequency
24 A @ 100 VAC system current rating
2353 W @ 100 VMaximum AC input power
RELATED DOCUMENTATION
SRX3600 Services Gateway AC Power Supply Electrical Specifications | 75
Power Requirements for AC-Powered SRX3600 Services Gateways | 79
SRX3600 Services Gateway AC Power Cord Specifications | 76
SRX3600 Services Gateway AC Power Cord Specifications
Each AC power supply has a single AC appliance inlet located on the power supply that requires a dedicated
AC power feed. Most sites distribute power through a main conduit that leads to frame-mounted power
distribution panels, one of which can be located at the top of the rack that houses the services gateway.
An AC power cord connects each power supply to the power distribution panel.
The services gateway is not shipped with AC power cords, you must order them separately using the model
number shown in Table 19 on page 77. The services gateway uses detachable AC power cords with C19
appliance couplers at the female end as described by International Electrotechnical Commission (IEC)
standard 60320. The plug at the male end of the power cord fits into the power source receptacle that is
standard for your geographical location.
Table 19 on page 77 provides specifications and Figure 37 on page 78 depicts the plug on the AC power
cord available for each country or region.
76
