SRX3600 Services Gateway Cabinet Airflow Requirements
When you mount the services gateway in a cabinet, you must ensure that ventilation through the cabinet
is sufficient to prevent overheating. Following is a list of requirements to consider when planning for
chassis cooling:
•
Ensure that the cool air supply you provide through the cabinet can adequately dissipate the thermal
output of the services gateway.
•
Allow at least 3 in. (7.6 cm) of vertical clearance between the top and bottom of the services gateway
and other devices in the cabinet.
•
Ensure that the cabinet allows the chassis hot exhaust air to exit from the cabinet without recirculating
into the services gateway. An open cabinet (without a top or doors) that employs hot air exhaust extraction
from the top allows the best airflow through the chassis.
•
Ensure that the cabinet provides at least 13 cm (5 in) of clearance on each side of the chassis for cooling
airflow.
•
If the cabinet contains a top or doors, you must provide perforations in these elements to allow adequate
airflow through the cabinet to dissipate the heat generated by all of the devices in the cabinet.
•
Route and dress all cables to minimize the blockage of airflow to and from the chassis.
For more information about air flow through the services gateway, see SRX3400 and SRX5600 Services
Gateways Air Deflector Kits.
RELATED DOCUMENTATION
SRX3600 Services Gateway Environmental Specifications | 64
Clearance Requirements for Airflow and Hardware Maintenance of the SRX3600 Services Gateway | 69
SRX3600 Services Gateway Cabinet Size and Clearance Requirements | 71
SRX3600 Services Gateway Rack Size and Strength Requirements | 67
SRX3600 Services Gateway Spacing of Mounting Bracket Holes | 69
72
