Replacing an AC Power Supply on the SRX3600 Services Gateway
NOTE: For the services gateway to meet NEBS and ETSI standards, all four AC power supplies
must be Revision 09 or later. See “SRX3600 Services Gateway NEBS and ETSI Compliance” on
page 316 for more information.
NOTE: The same AC power supply is used in both the SRX3400 and SRX3600 Services Gateways.
However, this power supply is not interchangeable with that used in the SRX1400 Services Gateway.
The SRX1400 Services Gateway power supply will fit into the SRX3600 Services Gateway, but will
not work properly. You can identify the SRX1400 Services Gateway power supply by the plastic
air filter assembly installed over the cooling air inlet as shown in Figure 78 on page 230.
Figure 78: Identifying Power Supply Types
g036110
Air filter
SRX3400 and SRX3600 DC Power Supply
SRX3400 and SRX3600 AC Power Supply
SRX1400 DC Power Supply
SRX1400 AC Power Supply
To replace an AC power supply:
1. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the ESD points on
the chassis. For more information about ESD, see Preventing Electrostatic Discharge Damage to the
SRX3600 Services Gateway.
2. Remove the power cord from the power supply.
3. Push the tab on the right edge of the power supply to the left.
230
