SRX3600 Services Gateway IOCs

I/O cards (IOCs) are common form-factor module (CFM) cards that provide additional physical network

connections to the services gateway to supplement the Ethernet ports on the Switch Fabric Board (SFB).

Their primary function is to deliver data packets arriving on the physical ports to the Network Processing

Card (NPC) and to forward data packets out the physical ports after services processing. The SRX3600

Services Gateway has six slots in the front of the chassis where you can install IOCs. You can install any

combination of IOCs in the slots. Figure 5 on page 16 shows a typical IOC.

Figure 5: Typical IOC (16-Port Copper 10/100/1000 IOC Shown, Other IOCs Similar)

g036031

NOTE: When the services gateway is in the Express Path (formerly known as Services Offload)

mode supported in Junos OS release 12.1X44-D10 and later, IOCs are only supported in front

panel slots 1 through 3. See the Junos OS documentation for more information about Express Path

mode.

For detailed information about the IOCs supported by the services gateway, see the SRX1400, SRX3400,

and SRX3600 Services Gateway Module Guide at www.juniper.net/documentation/.
