Data Flow in the SRX3600 Services Gateway
The services gateway receives data from the various physical interfaces on the I/O cards (IOCs). Incoming
data is passed through the Switch Fabric Board (SFB) to a Network Processing Card (NPC), back to the
SFB and on to a Services Processing Card (SPC). The data is then passed out of the services gateway in
reverse order—to the SFB, NPC, SFB, and out to the IOC.
