CHAPTER 5
Cooling System Description
IN THIS CHAPTER
SRX3600 Services Gateway Fan Tray | 51
SRX3600 Services Gateway Fan Tray
The cooling system consists of a fan tray containing 10 fans and an air filter. These components work
together to keep all services gateway components within the acceptable temperature range. The services
gateway has one fan tray located in the rear of the services gateway that installs vertically to the right of
the card cage. The fan tray is hot-insertable and hot-removable.
Figure 30: Fan Tray
51
