The serial number label for all IOC types is located as shown in Figure 23 on page 42).
Figure 23: IOC Serial Number Label (SRX3K-16GE-TX Shown, Other IOCs Similar)
g036078
Serial number
label
Serial Number
Location
RELATED DOCUMENTATION
SRX1400, SRX3400, and SRX3600 Services Gateway Module Overview | 27
Modules Supported on SRX1400, SRX3400, and SRX3600 Services Gateways | 28
Eligible Slots for SRX1400, SRX3400, and SRX3600 Services Gateway Modules | 30
Installing Common Form Factor Modules In SRX1400, SRX3400, and SRX3600 Services Gateways
Network Processing I/O Card SRX1K3K-NP-2XGE-SFPP
The Network Processing I/O card (NP-IOC) SRX1K3K-NP-2XGE-SFPP (Figure 6 on page 17) is an IOC
that includes its own Network Processing Unit (NPU), so that traffic traversing the NP-IOC does not have
to also traverse the services gateway bus to a remote NPC. This feature makes the NP-IOC well-suited to
low-latency applications . It is inserted horizontally into the midplane of the services gateway to
communicate with the SFB and to receive power. To use fiber interface media, install enhanced small
form-factor pluggable (SFP+) transceivers on the desired ports. LEDs on the faceplate of the NP-IOC
indicate port status and connectivity. The SFP+ ports are numbered from left to right, 0-1.
42
