CHAPTER 29
Replacing Cooling System Components
IN THIS CHAPTER
Replacing the Fan Tray on the SRX3600 Services Gateway | 223
Replacing the Air Filter on the SRX3600 Services Gateway | 226
Replacing the Fan Tray on the SRX3600 Services Gateway
The services gateway has one fan tray that installs vertically in the right rear of the chassis. The fan tray
contains 10 fans. The fan tray is hot-removable and hot-insertable. It weighs about 6.2 lb (2.8 kg).
NOTE: To prevent overheating, install the replacement fan tray immediately after removing the
existing fan tray.
To replace the fan tray:
1. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the ESD points on
the chassis. For more information about ESD, see Preventing Electrostatic Discharge Damage to the
SRX3600 Services Gateway.
2. Turn the screw to the left on the fan tray door. Open it to the right and remove it.
223
