Juniper SRX3600 Hardware Guide

Figure 10: Rear View of the SRX3600 Services Gateway
g036125
ESD
point
Chassis
grounding
point
Fan tray
door
CFM slots
for SPCs or
NP-IOCs
Cooling
air inlets
Routing Engine
in slot RE0
Power
supplies
Slot
number
guide
Slot RE1
for SCM
CFM slots for
SPCs, NPCs,
or NP-IOCs
RELATED DOCUMENTATION
SRX3600 Services Gateway Description | 3
SRX3600 Services Gateway CFMs | 7
Available Components for the SRX3600 Services Gateway | 5
Grounding the SRX3600 Services Gateway | 139
SRX3600 Services Gateway General Safety Guidelines and Warnings
Hardware Component Locations in the SRX3600 Services Gateway Chassis
The SRX3600 Services Gateway is populated with one SFB, one Routing Engine, two power supplies, and
a fan tray at the factory. You must install all other cards required to meet your configuration needs.
Table 8 on page 22 lists the possible locations of the various hardware components in the SRX3600
Services Gateway. Figure 11 on page 23 and Figure 12 on page 24 show the locations of the slots and the
applicable modules.
Table 8: Allowed Slot Locations for the SRX3600 Services Gateway Components
Allowed Slot LocationsModule Name
Front slot labeled 0.SFB
22
