RELATED DOCUMENTATION
Required Tools and Parts for Replacing Hardware Components on the SRX3600 Services Gateway | 200
Replacing the SFB on the SRX3600 Services Gateway | 207
Replacing a Routing Engine on the SRX3600 Services Gateway | 210
Replacing an AC Power Supply on the SRX3600 Services Gateway | 230
Replacing an SCM on the SRX3600 Services Gateway
When installed, the SRX Clustering Module (SCM) is located in the rear slot labeled RE1 on the services
gateway.
To replace the SCM:
1. Place an electrostatic bag or antistatic mat on a flat, stable surface.
2. Attach an ESD grounding strap to your bare wrist and connect the strap to one of the ESD points on
the chassis. For more information about ESD, see Preventing Electrostatic Discharge Damage to the
SRX3600 Services Gateway.
3. If you have not already done so, power off the services gateway by pressing the Power button on the
front panel of the SFB for three to five seconds.
The PWR LED blinks to show you that the services gateway is shutting down. Wait for the services
gateway to shut down before you proceed to the next step.
4. Loosen the captive screws at each end of the SCM faceplate.
5. Pull open the ejector handles to unseat the SCM.
6. Grasp the SCM by the ejector handles and slide it halfway out of the chassis.
220
