The serial number label is located as shown in Figure 27 on page 47).
Figure 27: Routing Engine Serial Number Label
g036084
Serial number
label
Serial Number
Location
RELATED DOCUMENTATION
SRX1400, SRX3400, and SRX3600 Services Gateway Module Overview | 27
Modules Supported on SRX1400, SRX3400, and SRX3600 Services Gateways | 28
Eligible Slots for SRX1400, SRX3400, and SRX3600 Services Gateway Modules | 30
Installing Common Form Factor Modules In SRX1400, SRX3400, and SRX3600 Services Gateways
SRX Clustering Module SRX3K-CRM
The SRX Clustering Module (SCM) is a card that you can install in the SRX3400 and SRX3600 Services
Gateway to enable the dual control link feature for chassis cluster supported in Junos OS Release 10.2
and later (Figure 8 on page 19). You install the SCM in the RE1 slot on the rear panel of the services
gateway.
Figure 28: SRX Clustering Module SRX3K-CRMSRX3K-CRM
47
