Troubleshooting with Chassis and Interface Alarm Messages on the SRX3600 Services Gateway | 177
Troubleshooting with LEDs on the SRX3600 Services Gateway
LEDs on the services gateway display the status of various components:
•
Common form-factor module (CFM) LED—One LED labeled OK/FAIL on the faceplate of each IOC,
NP-IOC, SPC, and NPC indicates the CFM’s status.
•
SFB LEDs—Ten LEDs, labeled ALARM (2 LEDs), SFB, HA, CFM SERVICE, CFM OK/FAIL, RE0, RE1,
PWR, and FAN, on the SFB faceplate indicate the status of the SFB. If no LEDs are lit, the Routing Engine
might still be booting or the SFB is not receiving power.
•
Routing Engine LEDs—Five LEDs, labeled MASTER, HDD, STATUS for the Routing Engine function,
STATUS for the PFE controller, and OK/FAIL for general board status, on the Routing Engine faceplate
indicate the status of the Routing Engine and hard disk drive.
•
SRX Clustering Module (SCM) LED—One LED, labeled OK/FAIL, on the SCM faceplate indicates the
status of the SCM.
•
Power supply LEDs—One LED on each power supply faceplate indicates the status of that power supply.
For detailed information about the LEDs on CFMs and other modules supported by the services gateway,
see the SRX1400, SRX3400, and SRX3600 Services Gateway Module Guide at
www.juniper.net/documentation/.
RELATED DOCUMENTATION
SRX3600 Services Gateway 16-Port Copper Ethernet/Fast Ethernet/Gigabit Ethernet IOCs
SRX3600 Services Gateway 16-Port SFP Gigabit Ethernet IOC
SRX3600 Services Gateway 2-Port XFP 10-Gigabit Ethernet IOCs
SRX3600 Services Gateway SPCs | 15
SRX3600 Services Gateway NPCs | 14
SRX3600 Services Gateway Switch Fabric Board | 7
SRX3600 Services Gateway Routing Engine | 18
SRX3600 Services Gateway SRX Clustering Module | 19
SRX3600 Services Gateway AC Power Supply Overview | 55
176
