10. ADJUSTMENT ITEM LIST Field Service Ver. 2.0 Jun. 2010
80
bizhub 164
ADJUSTMENT / SETTING
10. ADJUSTMENT ITEM LIST
*: Check when setting is changed.
Replacement Part/Service Job
Adjustment/Setting Items
No
Tray1
Replace drum Replace drum charge corona assy Replace developer Replace cleaning blade Replace feed roller Replace separation roll assy
SERVICE MODE
SER-
VICE’S
CHOICE
ID ADJUST 1 3* 5*
VG ADJUST 2 4* 1*
LEADING EDGE 3
TRAILING EDGE 4
VERTICAL EDGE 5
LOOP Ad. (TRAY1) 6 3* 3*
LOOP Ad. (BYPASS) 7
FUSER TEMP. 8
ADJUST
PRN MAIN 9
PRN SUB 10
CIS MAIN ZOOM 11
CIS SUB ZOOM 12
CIS MAIN REGIST 13
CIS SUB REGIST 14
CLEAR
DATA
PM COUNTER 15 1 1
SUPPLIES COUNETER 16 2 2 3 2
FUNC-
TION
PAPA E R F E ED T ES T 17 2 2
TCR AUTO ADJUST 18 1, 4
PRN TEST PATTERN 19 5 3 6
SCAN TEST 20
Others
UTILITY MODE 21
SERVICE MODE 22
Parameter chip (U18) 23
FW update 24
Application of toner to drum 25 1 1
Change of developer 26 2
