Konica Minolta BIZHUB 164 Service Manual

Field Service Ver. 2.0 Jun. 2010 3. PERIODICAL MIANTENANCE ITEMS
7
bizhub 164MAINTENANCE
MAINTENANCE
3. PERIODICAL MIANTENANCE ITEMS
3.1 Concept of periodical maintenance
•The cleaning or replacement cycle of the parts of the machine and options that
need periodical maintenance depends on the total counter value or each counter
value provided by [SERVICE MODE] - [COUNTER] - [PM COUNTER].
3.1.1 Main body
A. Periodical maintenance 1 (Total counter; every 55,000 counts)
B. Periodical maintenance 2 (PM counter; every 100,000 counts)
Section Description/part name Qt. Clean Check
Lubri-
cation
Replace
Descrip-
tions
Overall Paper feed and image conditions ⎯ ●
Appearance ⎯ ●●
Conveyance
section
Timing roller ⎯ ●
Pre-image transfer guide plate ⎯ ●
Processing
section
Ds collars ⎯ ●
Developer scattering
prevention plate
⎯ ●
Drum separator fingers ⎯ ●
Developer 1 ●
Drum 1 ●
Cleaning blade 1 ●
Drum charge corona assy 1 ●
Section Description/part name Qt. Clean Check
Lubri-
cation
Replace
Descrip-
tions
Fusing section Fusing unit 1 ●
