Konica Minolta BIZHUB 164 Service Manual

Field Service Ver. 2.0 Jun. 2010 13. JAM DISPLAY
127
bizhub 164
TROUBLESHOOTING
13.3.5 Misfeed at the fusing/exit section
A. Detection timing
B. Action
Type Description
Fusing/exit section
misfeed detection
• The exit paper sensor (PS3) is not unblocked even after the lapse of a given
period of time after the registration sensor (PS1) has been blocked.
Detection of paper
left in fusing/exit
section
• The exit paper sensor (PS3) is blocked at timing when the power switch is
turned ON, the cover is opened and closed, or a paper misfeed or malfunction
is reset.
Relevant electrical components
Registration sensor (PS1)
Exit sensor (PS5)
Registration clutch (CL1)
Main motor (M1)
Printer control board (PRCB)
Step Operations
WIRING DIAGRAM
Control signal
Location
(Electrical compo-
nents)
1Initial check items - -
2Check the connector between M1-PRCB
CN6 for proper connection and correct as
necessary.
--
3Check the M1 connector for proper drive
coupling and correct as necessary.
--
4Check the connector between PS1-relay
CN24-PRCB CN9 for proper connection
and correct as necessary.
--
5Check the connector between PS5-PRCB
CN4 for proper connection and correct as
necessary.
--
6Check the connector between CL1-relay
CN7-PRCB CN9 for proper connection and
correct as necessary.
--
7PS1 sensor check PRCB CN9-7 (ON) C-11
8PS5 sensor check PRCB CN4-4 (ON) E-3
9CL1 operation check PRCB CN9-2(REM) C-11
10 M1 operation check PRCB CN6-7 (LOCK) D-9
11 Replace PRCB. - -

Konica Minolta BIZHUB 164 Specifications

General

Print Technology	Laser
Print Speed	16 ppm
Print Resolution	600 x 600 dpi
Copy Speed	16 cpm
Copy Resolution	600 x 600 dpi
Scan Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Interface	USB 2.0
Warm-up Time	29 seconds
Paper Input Capacity	250 sheets
Memory	32 MB
Type	Monochrome
Maximum Paper Size	A3
Duplex Printing	Manual
Network Connectivity	No
USB Connectivity	Yes
Paper Size	A5
Fax Resolution	Not applicable
