Konica Minolta BIZHUB 164 Service Manual

Field Service Ver. 2.0 Jun. 2010 13. JAM DISPLAY
123
bizhub 164
TROUBLESHOOTING
13.3 Solution
13.3.1 Initial check items
•When a paper misfeed occurs, first perform the following initial checks.
Check item Action
Does paper meet product specifications? Replace paper.
Is the paper curled, wavy, or damp? Replace paper.
Instruct the user on the correct paper
storage procedures.
Is a foreign object present along the paper path, or is the
paper path deformed or worn?
Clean or change the paper path.
Are the paper separator fingers dirty, deformed, or worn? Clean or replace the defective paper
separator finger.
Are rolls/rollers dirty, deformed, or worn? Clean or replace the defective roll/roller.
Are the edge guide and trailing edge stop at the correct
position to accommodate the paper?
Set as necessary.
Are the actuators operational and checked for correct
operation?
Correct or replace the defective actuator.
Is the paper size setting correct? Check the paper size and reset as
necessary.
