Konica Minolta BIZHUB 164 Service Manual

16. IMAGE QUALITY PROBLEM Field Service Ver. 2.0 Jun. 2010
162
bizhub 164
TROUBLESHOOTING
16.2.23 Printer section: Periodically uneven image
A. Typical faulty images
B. Troubleshooting procedure
A09AF3C531DA
Step Check Result Action
1IU is securely fastened using the dedicated fixing screws. NO • Secure in position.
2PH unit is securely fastened using the dedicated fixing
screws.
NO • Secure in position.
3IU drive mechanism is dirty or damaged. YES•Clean or change.
4Drum surfaces in contact with Ds collars and drive mecha-
nism are dirty, scratchy, deformed, or worn.
YES • Clean or change.
5Registration roller drive mechanism is dirty, scratchy,
deformed, or worn.
YES • Clean or change.
6Fusing unit drive mechanism is dirty, scratchy, deformed,
or worn.
YES • Clean or change.
NO • Change printer control
board (PRCB).
