2. PRODUCT SPECIFICATIONS Field Service Ver. 2.0 Jun. 2010
2
bizhub 164
OUTLINE
2. PRODUCT SPECIFICATIONS
2.1 Type
2.2 Functions
Type Scanner/printer integrated desktop type
Scanning density 600 x 600 dpi
Platen Stationary
Original scanning CIS module optical scanning system
Scanning light source LED
Printing process Laser electrostatic printing system
PC drum type OPC drum: 9ST
Paper feeding system Tray 1: Separator pad system
Multi bypass tray: Small roller separation system with torque limiter
Exposure system LD exposing system/polygon mirror scan system
Exposure density 600 x 600 dpi
Developing system Dry 2 components developing method, HMT developing system
Charging system DC comb electrode scorotron system
Neutralizing system Non-erase
Image transfer system Roller image transfer system
Paper separating system Combination of curvature, separating claws system
Fusing system Roller fusing system
Heating system Halogen lamp
Types of original Sheets, books, and three-dimensional objects
Max. original size A3 or 11 × 17
Max. original weight 2 kg
Multiple copies 1 to 99
Warming-up time 220 - 240 V: 29 sec. or less
110 V/120 - 127 V: 30 sec. or less
(when the power switch is turned ON from a stabilized state at ambient
temperature of 23° C/73.4° F and rated source voltage)
Image loss Leading edge: 4 mm (3/16 inch), trailing edge: 4 mm (3/16 inch),
Rear edge: 4 mm (3/16 inch), front edge: 4 mm (3/16 inch)
First copy time
(A4, 8
1
/
2
x 11)
8 sec. or less
(Values in conditions of paper fed from tray 1 at a room temperature of
23°C and with a rated power source)
Processing speed 77 mm/s
Copying/printing speed for
multi-copy cycle
(A4, 8
1
/
2
x 11)
bizhub 164 16 sheets/min. (Plain paper)
7 sheets/min. (Card1/2)
To Next Page
