(1) Left control (traveling) lever (A) Pull
(B)
Backward
NOTE :
• When
the machine begins to travel backward,
the back-up alarm starts sounding.
IMPORTANT :
• If the temperature of the hydraulic oil is too low,
the back-up alarm may start sounding when
switching from the backward to the forward
travel. This alarm is not a problem.
Just run for warm-up, and then the hydraulic oil
temperature rises, this will stop the alarm. If the
alarm still keeps sounding, contact your local
dealer.
4. Turning the machine
CAUTION
T
o avoid personal injury:
• Before changing direction of the machine,
beware of people in the work area.
• Make sure that the bucket or attachment is
lowered on the ground.
4.1 How to use pivot turn
To turn the machine forward to the left
1. Tilt the left control (traveling) lever forward to the
left.
(1) Left control (traveling) lever (A) Tilt
(B)
Forward to the left
To turn machine backward to the left
1. T
ilt the left control (traveling) lever backward to the
left.
(1) Left control (traveling) lever (A) Tilt
(B)
Backward to the left
To turn machine forward to the right
1. T
ilt the left control (traveling) lever forward to the
right.
 OPERATION OPERATION OF THE MACHINE
