TECHNICAL DATA
SPECIFICATION TABLE
KUBOTA CTL (Compact Track Loader)
Model name SVL75-3
Type Closed Cab
Operating weight including operator's weight 4273 kg
Engine
Type Water cooled 4 cycle diesel engine with 4 cylinder
Model name KUBOTA V3307-TE5A
Total displacement 3331 cc
Engine power
SAE J1995 gross 55.4 kW
SAE J1349 net 54.6 kW
Rated speed 2400 rpm
Low idling speed 1150 rpm
Performance
Rated operating
capacity (ISO
14397-1)
Bucket 1129 kg
Pallet fork 794 kg
Tipping load (ISO
14397-1)
Bucket 3226 kg
Pallet fork 2268 kg
Breakout force
Bucket (ISO 14397-2) 2808 kg
Lift arm (ISO
14397-2)
2142 kg
Travel speed
Fast 13.7 km/h
Slow 9.0 km/h
Ground pressure
(With operator)
Standard track
(Width: 320 mm)
40.8 kPa
(0.42 kgf/cm
2
)
Wide track
(Width: 400 mm)
32.9 kPa
(0.34 kgf/cm
2
)
Battery capacity 12 V RC: 160 min, CCA 900 A
Pressure connection for
attachments
Max. displacement (Theoretical)
Standard Flow High-Flow
72.7 L/min 112.8 L/min
Max. pressure
22.0 MPa
(224 kgf/cm
2
)
Fuel tank capacity 95 L
NOTE :
• Specifications
are based on the machine with KUBOTA standard bucket. (Bucket weight: 216.5 kg, Bucket size: 1727 mm (68 in.) No
teeth, side cutter nor bolt-on cutting edge)
• Specifications are based on the machine with KUBOTA standard rubber track. (Track width: 320 mm (12.6 in.))
• Specifications are based on the machine with quick coupler.
• Specifications are subject to change without notice.
• Rated operating capacity is based on normal operating conditions with a maximum travel speed of 6 km/h. (ISO 14397-1)
• Operating weight is with 75 kg operator.
