10. Glow plug indicator
The
glow-plug-indicator is displayed when the engine
requires preheating.
Press the start switch when the machine is off, and
then the glow plug indicator lights up.
Wait until the glow plug indicator goes out, and then
start the engine.
NOTE :
• If the machine lockout function is enabled, the
glow plug indicator lights up after password
authentication is completed.
• When the engine is preheating, the message
“Eng. Preheating” is displayed.
(1) Glow plug indicator
11. Parking brake warning indicator
When the parking brake switch is turned on, the
parking
brake warning indicator on the instrument panel
turns on.
(See Parking brake switch on page 96)
(1) Parking brake warning indi-
cator
12. Bucket-floating indicator
While
in the bucket-float mode, the [
]
mark on the
instrument panel stays on.
(1) Bucket-float switch (2) Bucket-floating indicator
13. Self leveling indicator
While in the self leveling mode, the mark on the
instrument panel stays on.
(1) Self leveling switch (2) Upper indicator
INSTRUMENT PANEL INSTRUMENT PANEL AND SWITCH
