Fig [A]
(1) CCV internal pressure switch
11. Checking the relief valve
Consult your local KUBOTA dealer for checking the
relief valve.
BIENNIAL SERVICING
1. Replacing the hydraulic hose
Consult your local KUBOTA dealer for replacing the
hydraulic hoses.
2. Changing the radiator coolant
WARNING
To avoid personal injury or death:
• Do not open the radiator cap right after the
engine has been stopped. Serious burns can
occur from contact with escaping hot coolant
fluid.
• When using the antifreeze, use protective
clothing such as rubber gloves (antifreeze
contains poison).
• If you have swallowed the antifreeze, seek
medical attention at once.
• When the antifreeze comes in contact with the
skin or clothing, wash it off immediately.
• Do not mix different types of antifreeze. The
mixture can produce a chemical reaction
causing harmful substances or vapors.
• Antifreeze is extremely flammable and
explosive under certain conditions. Keep fire
and children away from the antifreeze.
• When draining fluids from the engine, collect
fluids with a some container underneath the
engine body.
• Do not pour waste onto the grounds, down a
drain, or into any water source.
• Follow the relevant environmental-protection-
regulations when disposing of the antifreeze.
• Antifreeze
if swallowed is poisonous to people,
animals, and birds.
1. Park the machine on a firm, flat and level surface.
2. Lower the lift arms to the ground.
3. Stop the engine.
4. Wait until the engine has cooled down completely.
5. Loosen the bolts and slide the under cover on the
bottom of the frame.
(1) Under cover
(2)
Bolt
(A) Slide
6. Slowly
loosen the radiator cap to relieve the
pressure in the radiator system, and then remove
the radiator cap.
ANNUAL SERVICING  MAINTENANCE
