Kyocera KM-5050 Service Manual

2GN/2GP/2GR-1
2-4-3
Periodic maintenance procedures
*Check and clean with alcohol when user call occurs.
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Test copy
and test print
Perform at the maxi-
mum copy size
Test copy Every service
Section
Maintenance
part/location
Method Maintenance cycle Points and cautions Page
Paper feed
section
Upper/lower paper feed
pulley
Replace 400K (30)
500K (40/50)
Replace.* P.1-5-3
Upper/lower separation
pulley
Replace 400K (30)
500K (40/50)
Replace.* P.1-5-3
Upper/lower forwarding
pulley
Replace 400K (30)
500K (40/50)
Replace.* P.1-5-3
MP paper feed pulley Replace 400K (30)
500K (40/50)
Replace.* P.1-5-5
MP separation pulley Replace 400K (30)
500K (40/50)
Replace.* P.1-5-5
MP forwarding pulley Replace 400K (30)
500K (40/50)
Replace.* P.1-5-5
MP feed roller 1 Clean 400K (30)
500K (40/50)
Clean with alcohol.*
MP feed pulley
Clean 400K (30)
500K (40/50)
Clean with alcohol.*
MP feed roller 2 Clean 400K (30)
500K (40/50)
Clean with alcohol.*
Left registration roller Clean 400K (30)
500K (40/50)
Clean with alcohol.*
Right registration roller Clean 400K (30)
500K (40/50)
Clean with alcohol.*
Feed pulley Clean 400K (30)
500K (40/50)
Clean with alcohol.*
Feed roller 1 Clean 400K (30)
500K (40/50)
Clean with alcohol.*
Feed roller 2 Clean 400K (30)
500K (40/50)
Clean with alcohol.*
Feed roller 3 Clean 400K (30)
500K (40/50)
Clean with alcohol.*
Registration switch Clean 400K (30)
500K (40/50)
Clean with a dry cloth.*
Left registration cleaner Replace 400K (30)
500K (40/50)
Replace. P.1-5-10
Registration guide Replace 400K (30)
500K (40/50)
Replace.
Right registration
cleaner
Replace 400K (30)
500K (40/50)
Replace. P.1-5-10
Transfer guide Replace 400K (30)
500K (40/50)
Replace.

Kyocera KM-5050 Specifications

General

electrical requirements	120V, 60Hz, 11.5A
max monthly volume	200, 000 Pages Per Month
warm-up time	Within 30 Seconds
first copy out	3.5 Seconds
pages per minute	50 Letter, 26 Legal, 26 Ledger
system memory	Standard 512MB RAM, upgradeable to 1GB
hard disk drive	Standard 80GB HDD
resolution	600 x 600 DPI
standard paper sources	Dual 500 Sheet Drawers, 200 Sheet MPT
drawer paper size	5.5" x 8.5" - 11" x 17"
paper weight	13-28 lb Bond via Paper Drawers, 13 lb Bond -110 lb Index via MPT
paper size	5.5" x 8.5" – 11" x 17"
paper weight	17 – 20 lb Bond
capacity	100 Sheet DSDP / 50 Letter Size Originals Per Minute
dimensions	22.4”W x 20.7”D x 5.9”H
weight	29 lbs
stack capacity	Main Tray (A): 3, 000 Sheets; Sub Tray (B): 200 Sheets, Sub Tray (C): 50 Sheets
dimensions	26.9"W x 22.2"D x 42.8"H
weight	121 lbs
number of trays	7
dimensions	20.1"W x 15.7"D x 18.5"H
weight	22 lbs
weight	6.6 lbs
dimensions	25.9"W x 17.9”D x 10.5"H
weight	53 lbs
dimensions	22.0"W x 20.7"D x 36.0"H
weight	55 lbs
dimensions	12.2”W x 16.1”D x 6.3”H
weight	19.8 lbs
dimensions	23.0”W x 23.6”D x 12.4”H
weight	50.7 lbs
dimensions	23.0”W x 23.2”D x 12.4”H
weight	57.3 lbs

Weight and Dimensions

dimensions	23.6"W x 25.4"D x 29.3"H
weight	188 lbs
