Kyocera KM-5050 Service Manual

2GN/2GP/2GR-6
1-3-63
U252
Setting the destination
Description
Switches the operations and screens of the machine according to the destination.
Purpose
To be executed after initializing the backup RAM by running maintenance item U020, in order to return the set-
ting to the value before replacement or initialization.
Setting
1. Press the start key.
2. Select the destination.
3. Press the start key. The setting is set.
4. Turn the main power switch off and on.
Supplement
The specified initial settings are provided according to the destinations in the maintenance items below. To
change the initial settings in those items, be sure to run maintenance item U021 after changing the destina-
tion.
Initial setting according to the destinations
U253
Switching between double and single counts
Description
Switches the count system for the total counter and other counters.
Purpose
Used to select, according to the preference of the user (copy service provider), if A3/Ledger paper is to be
counted as one sheet (single count) or two sheets (double count).
Setting
1. Press the start key.
2. Select double or single count.
Initial setting: DBL CNT(A3/LGR)
3. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
INCH Inch (North America) specifications
EUROPE METRIC Metric (Europe) specifications
ASIA PACIFIC Metric (Asia Pacific) specifications
Maintenance
item No.
Title Japan Inch Europe Metric,
Asia Pacific
208 Setting the paper size for the paper
feeder
A4 Letter A4
253 Switching between double and single
counts
Single Double Double
Display Description
SINGLE COUNT Single count for all size paper
DBL CNT(A3/LGR) Double count for A3/Ledger size or larger
DBL COUNT(B4) Double count for B4 size or larger
DBL CNT(FOL/LGL) Double count for Folio/Legal size or larger
