Kyocera KM-5050 Service Manual

2GN/2GP/2GR-2
1-3-65
U326
Setting the black line cleaning indication
Description
Sets whether to display the cleaning guidance when detecting the black line.
Purpose
Displays the cleaning guidance in order to make the call for service with the black line decrease by the rubbish
on the platen when scanning from the DP.
Setting
1. Press the start key.
2. Select ON or OFF.
Initial setting: ON
3. Press the start key. The setting is set.
Setting the count value
1. Enter a count using the +/- or numeric keys.
Setting range: 0 to 999
Initial setting: 8
When setting is 0, the black line cleaning indication is displayed only if the black line is detected.
2. Press the start key. The count is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U328
Side ejection setting
Description
Sets whether to eject to the side of the machine when an optional curl eliminator is installed.
Purpose
Set according to the preference of the user.
Setting
1. Press the start key.
2. Select ON or OFF.
Initial setting: OFF
3. Press the start key. The setting is set.
4. Turn the main power switch off and on.
Maintenance
item No.
Description
Display Description
ON Displays the cleaning guidance
OFF Not to display the cleaning guidance
COUNT Setting counts of the cleaning guidance indication
Display Description
ON To eject to the side of the machine
OFF Not to eject to the side of the machine
