Kyocera KM-5050 Service Manual

2GN/2GP/2GR-2
1-3-53
U240
Method: Checking the solenoid of the 3000-sheet document finisher
1. Select the item to be operated. The solenoid turns on for 1 s.
Method: Checking the motor and solenoid of the mailbox
1. Select the item to be operated. The operation starts.
2. To stop operation, press the stop key.
Method: Checking the motor of the centerfold unit
1. Select the item to be operated. The operation starts.
2. To stop operation, press the stop key.
Completion
Press the stop key with the operation stopped. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Solenoid
FEED IN SOL Paper entry solenoid (PESOL)
REAR DOWN SOL 1 Trailing edge holder solenoid 1 (TEHSOL1)
REAR DOWN SOL 2 Trailing edge holder solenoid 2 (TEHSOL2)
SUB PATH SOL Relief path solenoid (RPSOL)
SUB TRAY R SOL Feedshift solenoid 1 (FSSOL1)
SUB TRAY L SOL Feedshift solenoid 2 (FSSOL2)
BOOKLET SOL Feedshift solenoid 3 (FSSOL3)
PADDLE SOL Paddle solenoid (PDSOL)
HOLD DOWN SOL Paper holder solenoid (PHSOL)
EJECT SOL Pressure switching solenoid (PSWSOL)
PUNCH SOL Punch pattern solenoid (PPSOL)
M-TRAY LOCK SOL Lock solenoid (LSOL)
Display Motors and solenoids
FEED IN MOTOR Mailbox drive motor (MBDM)
BRANCH SOL 2 Tray feedshift solenoid 1 (TFSSOL1)
BRANCH SOL 3 Tray feedshift solenoid 2 (TFSSOL2)
BRANCH SOL 4 Tray feedshift solenoid 3 (TFSSOL3)
BRANCH SOL 5 Tray feedshift solenoid 4 (TFSSOL4)
BRANCH SOL 6 Tray feedshift solenoid 5 (TFSSOL5)
BRANCH SOL 7 Tray feedshift solenoid 6 (TFSSOL6)
FEED IN SOL Mail paper entry solenoid (MPESOL)
Display Motor
CONV MOTOR Centerfold main motor (CMM)
BLADE MOTOR Blade motor (BLM)
BUNDLE UP MOTOR Centerfold paper conveying belt motor 1 (CPCBM1)
BUNDLE DOWN MTR Centerfold paper conveying belt motor 2 (CPCBM2)
WIDTH TEST(A3) Centerfold side registration motor 1/2 (CSRM1/2)
WIDTH TEST(LD) Centerfold side registration motor 1/2 (CSRM1/2)
STAPLE MOTOR Centerfold staple motor (CSTM)
