Kyocera KM-5050 Service Manual

2GN/2GP/2GR-2
1-3-19
U024
HDD formatting
Description
Initializes the HDD.
In addition, the following settings are also initialized by initializing the HDD.
System menu (user login administration, job accounting, address book, one-touch keys and document box
etc.), shortcuts and panel programs
Purpose
To initialize the HDD when replacing the HDD after shipping.
Method
1. Press the start key.
2. Press [EXECUTE] on the touch panel.
3. Press the start key to initialize the hard disk.
4. Turn the main power switch off and on.
U030
Checking motor operation
Description
Drives each motor.
Purpose
To check the operation of each motor.
Method
1. Press the start key.
2. Select the motor to be operated.
3. Press the start key. The operation starts.
4. To stop operation, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U031
Checking switches for paper conveying
Description
Displays the on-off status of each paper detection switch on the paper path.
Purpose
To check if the switches for paper conveying operate correctly.
Method
1. Press the start key.
2. Turn each switch on and off manually to check the status.
When a switch is detected to be in the ON position, the display for that switch will be highlighted.
*: Optional.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Operation
FEED Paper feed motor operates
MAIN Drive motor operates
EJECT(FW) Eject motor rotates forward
EJECT(REV) Eject motor rotates in reverse
Display Switches
FEED1 Feed switch 1 (FSW1)
FEED2 Feed switch 2 (FSW2)
FEED3 Feed switch 3 (FSW3)
MP TRAY MP feed switch (MPFSW)
REGIST Registration switch (RSW)
EJECT Eject switch (ESW)
BRANCH Feedshift switch (FSSW)
DUPLEX Duplex paper conveying switch (DUPPCSW)
JOB SEPARATOR Job separator eject switch (JBESW)*
