Kyocera KM-5050 Service Manual

2GN/2GP/2GR-2
1-3-16
U019
Displaying the ROM version
Description
Displays the part number of the ROM fitted to each PWB.
Purpose
To check the part number or to decide, if the newest version of ROM is installed.
Method
1. Press the start key. The ROM version are displayed.
2. Change the screen using the cursor up/down keys.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Maintenance
item No.
Description
Display Description
MAIN Main PWB ROM IC
MMI Operation PWB ROM IC
ENGINE Engine PWB ROM IC
ENGINE BOOT Engine PWB booting
SCANNER Scanner PWB ROM IC
OPTION LANGUAGE Optional language ROM IC
DICTIONARY -
DP Optional DP main PWB ROM IC
LCF Optional 3000-sheet paper feeder main PWB ROM IC
OPTION CASSETTE Optional paper feeder main PWB ROM IC
DF MAIN Optional 3000-sheet document finisher main PWB ROM IC
DF MTRAY Optional 3000-sheet document finisher internal tray PWB
ROM IC
DF SADDLE Optional centerfold main PWB ROM IC
DF MAILBOX Optional mailbox main PWB ROM IC
INNER DF Optional built-in finisher main PWB ROM IC
SIMPLE DF MAIN Optional document sheet finisher main PWB ROM IC
FAX BOOT1 Optional fax control PWB booting (port 1)
FAX APL1 Optional fax control PWB APL (port 1)
FAX IPL1 Optional fax control PWB IPL (port 1)
FAX BOOT2 Fax control PWB booting (port 2: optional dual FAX)
FAX APL2 Fax control PWB APL (port 2: optional dual FAX)
FAX IPL2 Fax control PWB IPL (port 2: optional dual FAX)

Kyocera KM-5050 Specifications

General

electrical requirements	120V, 60Hz, 11.5A
max monthly volume	200, 000 Pages Per Month
warm-up time	Within 30 Seconds
first copy out	3.5 Seconds
pages per minute	50 Letter, 26 Legal, 26 Ledger
system memory	Standard 512MB RAM, upgradeable to 1GB
hard disk drive	Standard 80GB HDD
resolution	600 x 600 DPI
standard paper sources	Dual 500 Sheet Drawers, 200 Sheet MPT
drawer paper size	5.5" x 8.5" - 11" x 17"
paper weight	13-28 lb Bond via Paper Drawers, 13 lb Bond -110 lb Index via MPT
paper size	5.5" x 8.5" – 11" x 17"
paper weight	17 – 20 lb Bond
capacity	100 Sheet DSDP / 50 Letter Size Originals Per Minute
dimensions	22.4”W x 20.7”D x 5.9”H
weight	29 lbs
stack capacity	Main Tray (A): 3, 000 Sheets; Sub Tray (B): 200 Sheets, Sub Tray (C): 50 Sheets
dimensions	26.9"W x 22.2"D x 42.8"H
weight	121 lbs
number of trays	7
dimensions	20.1"W x 15.7"D x 18.5"H
weight	22 lbs
weight	6.6 lbs
dimensions	25.9"W x 17.9”D x 10.5"H
weight	53 lbs
dimensions	22.0"W x 20.7"D x 36.0"H
weight	55 lbs
dimensions	12.2”W x 16.1”D x 6.3”H
weight	19.8 lbs
dimensions	23.0”W x 23.6”D x 12.4”H
weight	50.7 lbs
dimensions	23.0”W x 23.2”D x 12.4”H
weight	57.3 lbs

Weight and Dimensions

dimensions	23.6"W x 25.4"D x 29.3"H
weight	188 lbs
